Two Piece Design Ball Valve

Caliper

What is a "Two-Piece Design", and how does it differ from other design concepts?

A "Two Piece Design" refers to a specific design approach used in various industries where a product or structure is divided into two distinct components or parts intended to work together harmoniously. The fundamental difference between the Two Piece Design and other design concepts lies in its modularity and interdependence. Unlike single-piece designs, which are unified entities, the Two Piece Design utilizes separate components that collaborate to form a cohesive whole. This design strategy offers flexibility, ease of assembly, and maintenance advantages, as each component can be manufactured and handled independently. Additionally, it allows for greater adaptability and customization, as designers can mix and match different pieces to achieve varying functionalities or aesthetics. The Two Piece Design often results in enhanced performance, efficiency, and user experience by harnessing the synergistic relationship between its two components.

Two Piece Ball Valve, 2 Piece Design Ball Valves, 2 Piece Ball Valve, Two Piece Design Flanged Ball Valve, Cast Iron Two Piece Ball Valve, Two Piece Design Ball Valve Supplier In Mumbai, India.

Shape 2
Shape 3
Two Piece Design Ball Valves

Two Piece Design Ball Valve Suppliers, Flanged End Two Piece Ball Valve, Screw End Two Piece Design Ball Valve, Regular Bore Two Piece Design Ball Valve, Reduce Bore Two Piece Design Ball Valve, Low Torque 2 Piece Ball Valve, Two Piece Design Ball Valve Exporter In India.

What are the key advantages of using a two-piece design in various industries?

Utilizing a Two Piece Design in various industries offers several key advantages, making it an appealing choice for product development and manufacturing. Firstly, the modularity of the design allows for simplified production processes and assembly, reducing manufacturing complexities and costs. Each component can be produced independently, streamlining the manufacturing workflow and enhancing efficiency. Secondly, the Two Piece Design promotes ease of maintenance and repair. In the event of damage or wear, only the affected component needs replacement, reducing downtime and extending the product's lifespan.

This design approach facilitates easy customization, where different combinations of components can cater to diverse needs and preferences, providing versatility and adaptability in the market. Furthermore, transportation and logistics benefit from the reduced space requirements due to the separable nature of the design, leading to cost savings and improved distribution efficiency. Ultimately, the Two Piece Design's ability to enhance performance, reduce costs, and increase user convenience makes it a valuable option across various industries.

2 Piece Design Ball Valve Specification

Design Standards BS EN ISO 17292 (BS 5351) / BS EN ISO 12516 / BS EN 1983 / ASME B 16.34 / API 6D
Inspection & Testing Standard BS EN ISO 12266 – I (BS 6755 – I)
Fire Safe Testing Standard BS EN ISO 12266 – II / API 607
Flange To Flange Distance As Per ANSI B 16.10 / Tailor Made on Request
End Connection Flanged End to ANSI B 16.5, Class 150 / 300 / 600, BS 10 Table D / E / F / H, PN 6 / PN 10 / PN 16 / PN 25 / PN 40 / PN 64, DIN Standard / JIS Standard / IS Standard
Manufacuring Size Range 1/2" (DN15) to 6"(DN 150)
Pressure Rating of Valve 150# / 300# / 600# / 800#, PN 10 / PN 16 / PN 25 / PN 40 / PN 64
Valve Operation Manual Hand Lever / Worm-Gear Actuator Operated
Pneumatic Rotary Quarter Turn Actuator / Electrical Actuator
Body & Insert ASTM A 216 GR. WCB (Cast Carbon Steel)
ASTM A 351 GR. CF 8 / CF 8M (SS 304 / SS 316)
ASTM A 351 GR. CF 3 / CF 3M (SS 304L / SS 316L)
ASTM A 351 GR. CN7M / ASTM A351 Gr. CF8C
ASTM A351 Gr. CD4Mcu / ASTM A351 Gr. CK3MCuN
ASTM A352 Gr. LCA / LCB / LCC
NACE MR0175 / NACE MR
Ball ASTM A 351 GR. CF 8 / CF 8M (SS 304 / SS 316)
ASTM A 182 F304 / F316 (SS 304 / SS 316)
ASTM A 351 GR. CF 3 / CF 3M (SS 304L / SS 316L)
ASTM A 182 F304L / F316L (SS 304L / SS 316L)
ASTM A 351 GR. CN7M / ASTM A351 Gr. CF8C
ASTM A351 Gr. CD4Mcu / ASTM A351 Gr. CK3MCuN
Stem 304 / 316 (SS 304 / SS 316) ASTM A 276 T
304L / 316L (SS 304L / SS 316L) ASTM A 276T
ASTM A 276 T – 410 (SS 410)
Application & uses Power Plants
Process Industries
Petrochemical Plants
Refineries
Fertilizers Plants
Distillery Plants
Sugar Industries
Water, Steam, Gas, Oil & Other Non-aggressive media

Two-Piece Ball Valve Stock Availability

Two Piece Ball Gate Valve

Stainless Steel Two Piece Design Ball Valve

Because they are constructed of steel and have a high level of corrosion resistance, stainless steel valves are particularly durable. Steel valves can withstand both extremely high and low temperatures. Brass or plastic valves are typically only rated for a narrower range of working temperatures than steel valves.

SS Two Piece Design Ball Valve, Stainless Steel Two Piece Design Ball Valve, Full Port Stainless Steel Two Piece Design Ball Valve, Stainless Steel Two Piece Ball Valve, Stainless Steel Two Piece Design Ball Valve Exporter, 800# SS Two Piece Ball Valve, Stainless Steel 2 Piece Ball Valve Price, 300# SS Two Piece Ball Valve, 150# SS Two Piece Design Ball Valve, 600# SS Two Piece Ball Valve, SS Two Piece Design Ball Valve Supplier, Standard Port Stainless Steel Two Piece Design Ball Valve.

Two Piece Ball Globe Valve

Carbon Steel Two Piece Design Ball Valve

Carbon steel valves are utilised in hydraulic-based applications because of their great resistance to the corrosive tendencies of water and other liquids. It has excellent mechanical qualities and strengthens and extends the life of the valve mechanism due to its high carbon content.

Carbon Steel Two Piece Design Ball Valve, CS Two Piece Design Ball Valve, 800# CS Two Piece Ball Valve, 300# CS Two Piece Ball Valve, Standard Port Carbon Steel Two Piece Design Ball Valve, Carbon Steel Two Piece Ball Valve, Carbon Steel Two Piece Design Ball Valve Exporter, CS Two Piece Design Ball Valve Supplier, 150# CS Two Piece Design Ball Valve, Carbon Steel 2 Piece Ball Valve Price, 600# CS Two Piece Ball Valve, Full Port Carbon Steel Two Piece Design Ball Valve.

Two Piece Ball Check Valve

Cast Iron Two Piece Design Ball Valve

Cast iron valves are frequently employed in a variety of applications, such as utility systems in different industrial plants, air conditioning and plumbing in buildings, fire fighting apparatus, and water and sewer lines.

300# Cast Iron Two Piece Ball Valve, Cast Iron Two Piece Design Ball Valve, Cast Iron Two Piece Design Ball Valve Exporter, 600# Cast Iron Two Piece Ball Valve, 800# Cast Iron Two Piece Ball Valve, Standard Port Cast Iron Two Piece Design Ball Valve, Cast Iron Steel Two Piece Design Ball Valve, Full Port Cast Iron Two Piece Design Ball Valve, Cast Iron Two Piece Design Ball Valve Supplier, Cast Iron Two Piece Ball Valve, Cast Iron 2 Piece Ball Valve Price, 150# Cast Iron Two Piece Design Ball Valve.

Two Piece Ball Ball Valve

Alloy Steel Two Piece Design Ball Valve

Alloy Steel Valves that are developed using raw materials that meet or exceed national and international standards. A Two uninterrupted flow of processes from foundry operation is the key characteristic of alloy steel valves.

AS Two Piece Design Ball Valve Supplier, Alloy Steel Two Piece Ball Valve, AS Two Piece Design Ball Valve, 800# Alloy Steel Two Piece Ball Valve, Standard Port Alloy Steel Two Piece Design Ball Valve, Full Port Alloy Steel Two Piece Design Ball Valve, 600# Alloy Steel Two Piece Ball Valve, Alloy Steel 2 Piece Ball Valve Price, Alloy Steel Two Piece Design Ball Valve Exporter, 150# Alloy Steel Two Piece Design Ball Valve, 300# Alloy Steel Two Piece Ball Valve, Alloy Steel Two Piece Design Ball Valve.

High-Quality Two Piece Ball Valve, High Pressure Two Piece Design Ball Valve, Heavy Duty 2 Piece Ball Valve, Threaded End Two Piece Design Ball Valve, Industrial Two Piece Ball Valve, Two Piece Design Ball Valve Stockist In Mumbai.

“View Two piece design ball valve pressure rating, Contact us today to know Two piece ball valve best offers & prices.”

Two Piece Design Ball Valve Component Name, Quantity & Dimension

Dimension
No. Component Name Qty.
1 Body 1
2 Adaptor 1
3 Ball 1
4 Stem 1
5 Seat Ring 2
6 Anti-Static Device 2
7 Stem Bottom Bush 1
8 Stem “O” Ring 1
9 Gland Packing 3
10 Gland Bush 1
11 Spring Washer 2
12 Gland Nut 2
13 Lever Stopper 1
14 Lever 1
15 Indicator or Washer” Ring 1
16 End Piece “O” Ring 1
17 Gasket 1
18 Stopper Pin 1
19 Lever Grip 1
20 Body Stud 6
21 Body Bolt 12
Size L F Wt. H E
DN NPS Cl 150 Cl 300 Cl 150 Cl 300 Cl 150 Cl 300 Cl 150 Cl 300
15 1/2 108 140 90 120 38 38 1 2
20 3/4 117 152 97 120 45 45 2 3
25 1 127 165 97 158 55 55 3 4
40 11/2 165 190 122 212 75 75 5 6 F05 F05
50 2 178 216 142 212 103 103 9 12 F07 F07
65 21/2 190 241 390 175 175 14 20.5 F07 F07
80 3 203 282 390 185 195 19 28 F07 F07
100 4 229 305 * 235 247 31 45 F10 F12
150 6 394 403 ** 285 315 78 105 F12 F14
200 8 457 502 980 345 371 141.5 169 F14 F16
